Project

Unit

Numerical value

Locking force

kN

8000

Locking stroke

mm

760

Die casting mold thickness (minimum maximum)

mm

400-950

Template size (horizontal x vertical)

mm

1420×1420

Distance between bars (horizontal x vertical)

mm

930×930

Pulling bar diameter (Goering column)

mm

Φ180

Injection force (pressurization)

kN

645

Injection stroke

mm

760

Injection chamber diameter

mm

φ 80,φ 90,φ 100

Shot quantity (aluminum)

kg

7.1,9.0,11.1

Casting pressure (pressurization)

MPa

128,101,82

Casting area

cm²

620,784,963

Maximum casting projection area (including gate, etc., when the injection ratio is 40Mpa)

cm²

2000

Injection position

mm

0,-250

The distance between the injection head and the exit

mm

300

Pressure chamber flange diameter

mm

200

The height of the pressure chamber flange protruding from the fixed plate

mm

20

Top output

kN

360

Top out itinerary

mm

180

Oil pump motor power

kW

45

Although the working pressure of the pressure system

MPa

16

Fuel tank capacity

L

1200

Machine weight

kg

40000

Machine dimensions (length x width x height)

m

8.5×2.42×3.22
